Place of Origin: | Lu'An, China |
---|---|
Brand Name: | ChenYu Technology |
Certification: | ISO9001, ISO14001, CE |
Model Number: | 5HCY-35 |
Minimum Order Quantity: | 1 Set |
Packaging Details: | Wooden Case |
Delivery Time: | 30 Working Days |
Supply Ability: | 100 Sets per Month |
Type: | Maize Dryer Plant | Loading Capacity: | 32000 KG |
---|---|---|---|
Net Weight: | 8000 KG | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
Applicable Industries: | Food & Beverage Factory, Farms, Food Shop, Food & Beverage Shops | Use: | Maize Drying |
Dimension: | 4770*5400*13737 | Power: | 21.35KW |
High Light: | 35T Maize Dryer Machine,21.35KW Maize Dryer Machine,35T Maize Dryer Plant |
Paddy Dryer System
Chenyu Dryer can be systemized to suit customer’s capacity requirements.
By the system, energy produced by husk burner (option) is utilized efficiently.
Automatic Control Software
Our Chentu Dryer is equipped with full color touch panel and automatic control software. Chenyu developed software provides full automatic drying operation to dry down the product to the target moisture with an ideal drying pattern to achieve the low crack rate after drying.
The Best Solution in Drying
Chenyu Dryer gives you the best solution to the problems in drying by means Chenyu original calibration formula and automatic control of hot air, circulation speed & air volume.
Single Grain Moisture Meter
High accuracy single grain moisture meter (Made in Japan) capable of continuously measuring every kernel. Measurement stability is immune to immature grains containing high moisture content. Any foreign materials ingress during measurement, are discharged automatically.
Outside Humidity Sensor
In addition to ambient temperature sensor, humidity sensor is also equipped to collect more information to calculate ideal drying pattern and speed.
Parameters:
Model | 5HHCY-32 | 5HHCY-35 |
Structure type | Batch type | |
Drying way | Indirect heating | |
diemension (L×W×H)mm |
3500×3000×11427 | 3500×3000×11955 |
diemension (L×W×H)mm |
4770*5400*13737 | 4770*5400*14375 |
Batch volume | 32 | 35 |
Drying rate | 0.5~1.2 | 0.5~1.2 |
Motor power of hot air blower | 4.0+5.5×2 | 4.0+5.5×2 |
Total power of dryer motor | 21.35 | 21.35 |
Cross drying technology
35T dimension for 35Ton
